Home Booster Compressor

O2 Booster Compressor

Oil-Free Medical Oxygen Compressor for Cylinder Filling (5, 10, 15, 20, 25, 30, 40, 50, 60, 140 Nm3/h)

Oil-Free Medical Oxygen Compressor for Cylinder Filling (5, 10, 15, 20, 25, 30, 40, 50, 60, 140 Nm3/h)

The oil-free oxygen compressor is especially suitable for medical oxygen compression and oxygen cylinder filling. The biggest advantage of this series is safety and reliability. 100% oil-free, that is, the whole machine is completely oil-free. No pollution to the compressed medium, simple control, automatic working system, no leakage, and convenient maintenance are the reasons why customers choose.

  • Product Details

Technical Parameters:

Displacement: 5 ~ 140Nm3/h

Inlet pressure: 0.2~0.4mpa adjustable
Exhaust pressure: 15/20mpa (150/200 bar)
Cooling method: air cooling, water cooling

Product Description:

Product Parameter

Model
Intake pressure
(Mpa)
Exhaust pressure
(Mpa)
O2 flow
(Nm3/h)
Motor Power
(KW)
Import size Export size Size(mm) Weight(kg) Rotating speed(r/min)
GOW-5/4-150 0.4 15 5 4.0  Rc1/2 G5/8 1350*850*1100 380 470
GOW-10/4-150 0.4 15 10 5.5  Rc1/2 G5/8 1350*1050*1100 410 470
GOW-15/4-150 0.4 15 15 7.5  Rc1/2 G5/8 1350*1050*1100 420 640
GOW-20/4-150 0.4 15 20 7.5  Rc1/2 G5/8 1350*1050*1100 430 580
GOW-25/4-150 0.4 15 25 11.0  Rc1/2 G5/8 1350*1050*1100 430 640

!!If there are technical parameters that require greater displacement, please send me a message!!!
