TUC3016A/B mechanized concrete spraying manipulator is specially designed for spraying concrete projects under difficult construction conditions. Designed to automatically perform wet and dry sprayed concrete construction. This machine is very suitable for slope stabilization or mining and tunnel construction that require small manipulators. The wireless remote control can be used to provide complete mobility and improved safety by allowing the operator to stay away from newly excavated rocks and newly sprayed concrete.
Internal combustion-hydrostatic drive Four-wheel drive (4WD)
Four-wheel steering (4WS) two-way driving
1. Engine
Cummins diesel engine output power: 93KW/2200rpm
2. Passed to
DA automatically controls the hydrostatic pressure
to the system
3. Driving speed
Low gear 0-3kw/h High gear 0-17kw/h
4. Climbing ability
46%(25°)
5. Suspension swing angle
±10°,Make the chassis better adapt to uneven
roads
6. Turn
Hydraulic four-wheel steering (4WS),with eight
character,half-eight-character, and diagonal mode
7. Minimum turning radius
2200mm inside, 6000mm outside
8. Driving direction
The cab layout direction is consistent with the
driving direction
9. Whole machine weight
17T
10.Overall dimensions
8600*2440*3500
shotcrete machine rental
