Low-pressure Screw Air Compressor, the Pressure Is 0.3Mpa, 0.4Mpa and 0.5Mpa
With Permanent Magnet Frequency Conversion Technology, Energy Saving, High Efficiency, and Sufficient Air Volume
Low Pressure Direct Driven Permanent Magnetic Screw Air Compressor
Product Description：
Highly Eficlency and Energy Saving Screw Airend
The low-pressure main engine adopts large rotor and low speed design to reduce internal leakage, improve volumetric efficiency, reduce bearing load and improve the life of the main engine.
Highly Eficient and Energy-saving Permanent Magnetic Motor
The main motor is a carefully selected IP54 high-efficiency energy-saving permanent magnet motor according to the needs of air compressor applications. All of them meet the national first-class energy efficiency standards. Torque and load can meet special design standards, so that the motor efficiency and power factor under load conditions. optimize. This optimized coefficient has an advantage of about 5% to 8% compared to other motor efficiencies.
Highly Eficlent Energy Saving Oll Dstibutin System
Patented high-efficiency oil and gas separator, special simplified design, aggregate separator core and oil return device, service life up to 6000 hours, oil filter, low pressure drop design, service life up to 4000 hours, high filtration accuracy Protect the bearing and the screw machine rotor.
The air filter does not change the direction of air flow, and directly passes through the filter medium to reduce pressure loss. It is more energy-efficient than traditional air filter, with large filtering area, higher precision and longer life.
Technical Parameters of Low Pressure Screw Air Compressor
| Model | Capacity | Pressure | Spssd | Pipe Diameter | Weight | Noise | Dimensions |
| m3/min | bar | rpm | KGS | Db(A) | L*W*H mm | ||
| SGPM 37 | 11.02 | 3 | 3050 | 2" | 920 | 67±2 | 1750*1200*1500 |
| 9.36 | 4 | 2600 | |||||
| 8.24 | 5 | 2300 | |||||
| SGPM 45 | 10.80 | 4 | 3000 | 2" | 950 | 67±2 | 1750*1200*1500 |
| 10.02 | 5 | 2800 | |||||
| SGPM 55 | 17.30 | 3 | 2600 | 2" | 1150 | 67±2 | 1750*1200*1500 |
| 15.34 | 4 | 2300 | |||||
| 13.31 | 5 | 2000 | |||||
| SGPM 75 | 23.01 | 3 | 3100 | DN65 | 2850 | 70±2 | 2500*1600*1800 |
| 19.71 | 4 | 2940 | |||||
| 17.97 | 5 | 2700 | |||||
| SGPM 90 | 22.14 | 4 | 3000 | DN65 | 2950 | 70±2 | 2500*1600*1800 |
| 20.67 | 5 | 2800 | |||||
| SGPM 110 | 34.07 | 3 | 2400 | DN100 | 3800 | 72±2 | 3000*1600*1900 |
| 29.48 | 4 | 2100 | |||||
| SGPM 132 | 39.83 | 3 | 3000 | DN100 | 4000 | 72±2 | 3000*1600*1900 |
| 35.20 | 4 | 2800 |
Product Application
